Typical Residential Water Flow Rate

Most of us don’t know what a flow rate number is until we experience a pressure drop in the bathtub or under the shower. That's when we start to wonder how much water really gets through our faucets.

Do you want to learn what a house water flow rate is? No problem, we’ll tell you. It is a simple measurement of how much liquid passes out of your faucet at a given instant.

Knowledge of the average flow rate of water in the house is especially essential when choosing a proper whole-house water filtration for your home.

In this article, you’ll learn everything there is to know about the average water flow rate for homes, why it’s so important, and how to quickly calculate it. Continue reading to start learning.

How to calculate your home water flow rate?

Calculating the average water flow rate in a house is not rocket science. You can do the maths by hand or get an online calculator.

Here’s what you’ll need to calculate it:

• The size of your pipe, usually the diameter (measured in ft)
• The velocity of liquid passing through your pipes: Measures how fast it gets through these pipes (ft/sec). This is a pretty standard number that can be estimated.

Water source	Maximum Velocity (ft/s)	Maximum Velocity (m/s)
General Water	3 - 8	0.9 - 2.4
Tap	1.6 - 8.2	0.5 - 2.5
Cooling	4.9 - 8.2	1.5 - 2.5
Process	5 - 10	1.5 - 3
Condensate	3.3 - 6.5	1.0 - 2.0
Suction Boiler feed	1.6 - 3.3	0.5 - 1.0

Formula

Without going through an online calculator, here’s how you’ll quickly calculate the rate for each home pipe:

Flow rate = Area of pipe (sq ft) x velocity of water (ft/sec)

Where…

Area of pipe = π * radius²

If the diameter is given…

Area of pipe = ¼ * π * diameter²

Therefore, Flow rate = ¼ * π * diameter² * velocity of water in the pipe.

Don’t let the formulas trouble you, it’s a pretty straightforward calculation, as you would see on the summary board above.

Example: What is the average GPM for a house, with liquid traveling at 10 ft/sec in a 25-inch pipe?

Solution:

Diameter = 25 inches = 2.5 ft

Flow rate = ¼ * 3.142 * (2.5 ft * 2.5 ft) * 10 ft/sec = 49.094 cubic ft/sec

Note: Although the rate is calculated in cubic ft per second, most filter suppliers prefer to use gallons per minute (GPM). This means whatever value you compute has to be converted to GPM. Which is easy!

1 cubic foot = 7.48 Gallons, 1 sec = 1 / 60 min

Thus, for our example above, Flow rate = 22,034.75 GPM

How many gallons does your home need?

How many gallons your home needs over a period of time will always come down to preference and the size of your home. By size, we mean the number of individuals who live in your home and the square footage of your house.

An average household uses over 300 gallons of water a day, which equates to about 75 gallons per individual.

What is the average household flow rate?

The typical GPM for a house is 6 GPM (recommended) — for water from a well or spring. This flow rate can provide 360 gallons of liquid per hour, which would be sufficient to meet most home needs.

Factors that can affect the home water flow rate

Here are some of the major factors that can affect the flow rate of your home. When the bathtub suddenly runs out of flowing water, you will have a better idea of what the problem is and quickly find a solution:

Number of members in the house

The average size of a household in the US is 4 individuals. A home with more than 4 people is considered a large household. The higher the number of people using water in a home, the higher the possibility of a low flow rate.

What reduces the pressure is the probability that multiple people will be using water at the exact same time.

Source: Statista

Square footage of the home

Square footage has a major impact on flow rate.

A typical residential water flow rate is calculated as…

The number of bedrooms x 2 people/bedroom x gpd x 1.75 (peaking factor) = gpd.

This goes for homes with 2000+ square feet.

For example, a 12,000 square-foot home with 7 bedrooms is calculated thus:

(7 x 2) x 130 x 1.75 = 3185 gpd.

Water pressure

The pressure in pipes is another factor to consider. If your source supplies water to your pipes at a relatively lower velocity, the pressure will also drop.

Broken pipes, fixtures, or appliances

Broken pipes are poison to your flow rate. There will obviously be a drop in the number of flowing gallons per minute if your pipes leak. Home appliances can also affect how much water comes out of your faucets.

Your house's plumbing size

This in simple terms refers to the dimensions of pipes that run through your home. Your plumber will tell you that the standard dimension of pipes is between 100 mm to 600 mm.

Remember the formula for calculating the flow rate? The larger the area of your pipe, the higher the flow rate, and vice versa.

Why is water flow rate important?

It is important to know your desired flow rate, especially when shopping for a proper home water filter. You need a filter that can handle the incoming pressure from your pipes and that can last up to the recommended 6-month lifespan before replacement.

Final Thought

You’ve learned about everything a homeowner should know when purchasing water filters for whole house. This won’t make you a world-class plumber, but it’s enough to help you make informed purchasing decisions.

Wondering to get the best filters for your home? Try Filterway. Home to high-quality carbon water filters that last, and the best customer service.

For more detailed information, you can refer to the water flow rate formula.
